Canon Colorado M Series UV Gel Printers

Canon Colorado M Series UV Gel Printers

1 2 3 4 5

SKU:
88 00 6175C029AA
Weight:

5 versions of one machine are available to perfectly fit your needs.

M3 Series:

  • M3 Base:  Glossy printing only, average production speed around 195sf/hr*
  • M3W:  Same as above but with white capability
  • M3 PRO:  Adds glossy & matte print modes, double sided printing
  • M3W Pro:  All available features in the M3 lineup including white ink

M5 Series:

  • M5 Pro:  Average print speeds around 300-400sf/hr*, FlxFinish+, double sided printing
  • M5W Pro:  All available features in the M Series including white ink

*print speeds change depending on print media.  Some media, like cast, can require slower print speeds.  Call us to have a discussion

M = Modular!

The Canon Colorado M Series allows printers to choose a level or production or options which best fit their needs.  The machine itself is the same across all of the options, and the unit can be upgraded in the field in order to add features or options to improve their output.  The M3 is a slower model and the M5 allows for more production speeds.  White is available on both platforms and can be added at any time.  Pricing and promotions change all the time, so please contact us for more information if the Colorado appears to be a great fit for your shop!

The Flexible Choice
Powered by Canon UVgel Technology

Colorado series of roll-to-roll printers have been fine-tuned to fit your business needs. Print Service Providers (PSPs) now have a clear choice that will deliver real production efficiency while lowering operating costs and increasing profits. Featuring FLXfinish+ matte/gloss finish, dual-roll drawer, and double-sided printing – the choice is yours!

The newest member of the family, the Colorado M-series, boasts a modular platform, suited for those who are looking for a scalable solution with options to upgrade later as your business needs change.

White ink Without Worry

Developed for the Colorado M-series, our UVgel ink set now reduces many of the hassles associated with white ink. The key is in the inks unique UVgel formula. The unique UVgel formula significantly reduces clogged heads common in evaporative technologies and keeps the pigments suspended in the ink longer. These properties mean there is no need to remove and store heads, nor shake ink bags before printing. Our highly productive UVgel white ink works as any other color and uses 50-70% less ink in the process. It has the flexibility that you expect for all your white applications and creates smooth layers –even up to five layers thick.

FLXfinish+: One Click, Two Finishes, One Print

FLXfinish+ is a revolutionary NEW technology for Canon Colorado printers that allows PSPs to command a premium price for their prints, while not incurring additional costs. Print gloss AND matte on the same print without a varnish or additional consumables.

Command Premium Prices On:

  • Wallcoverings
  • Labels
  • Packaging
  • Posters
  • Vehicle Graphics

The Colorado printer series can print matte AND gloss on one print in one pass because of the unique and award-winning UVgel 460 inks. With this ink, the only difference between the matte and the gloss finish is when the UVgel inks are cured. There is nothing like our NEW technology on the market! Start implementing FLXfinish+ and easily create beautiful striking output to make your business unique!



Some of the best SHORT videos about the Colorado:





Technical Specifications

Main Unit Specs
Colorado M3 Colorado M5
Printing
Printing Method UVgel piezoelectric inkjet UVgel piezoelectric inkjet
Printing Modes: Gloss High Key: 1,195 ft2/hr
Express: 840 ft2/hr
Speed: 592 ft2/hr
Production: 420 ft2/hr
High Quality: 312 ft2/hr
Premium: 237 ft2/hr
Specialty: 215 ft2/hr
High Key: 1,709 ft2/hr
Express: 1,229 ft2/hr
Speed: 861 ft2/hr
Production: 610 ft2/hr
High Quality: 427 ft2/hr
Premium: 290 ft2/hr
Specialty: 222 ft2/hr
Printing Modes: Matte** Express: 388 ft2/hr
Speed: 291 ft2/hr
Production: 237 ft2/hr
High Quality: 194 ft2/hr
Specialty: 140 ft2/hr
Backlit: 194 ft2/hr
Backlit Density: 108 ft2/hr
Express: 495 ft2/hr
Speed: 409 ft2/hr
Production: 333 ft2/hr
High Quality: 290 ft2/hr
Specialty: 215 ft2/hr
Backlit: 215 ft2/hr
Backlit Density: 108 ft2/hr
Printing Modes:
Mixed Matte/Gloss**
FLXfinish+: 75 ft2/hr FLXfinish+: 75 ft2/hr
Printing Modes:
Spot White 1 Layer**
Express: 291 ft2/hr
Speed: 237 ft2/hr
Production: 194 ft2/hr
High Quality: 140 ft2/hr
Specialty: 129 ft2/hr
Express: 388 ft2/hr
Speed: 323 ft2/hr
Production: 258 ft2/hr
High Quality: 194 ft2/hr
Specialty: 129 ft2/hr
Printing Modes:
White Underflood/Overflood 2 Layers*
Speed: 215 ft2/hr
Production: 151 ft2/hr
High Quality: 108 ft2/hr
Specialty: 75 ft2/hr
Speed: 215 ft2/hr
Production: 151 ft2/hr
High Quality: 108 ft2/hr
Specialty: 75 ft2/hr
Printing Modes:
White 3 Layers**
High Quality: 75 ft2/hr
Specialty: 54 ft2/hr
High Quality: 75 ft2/hr
Specialty: 54 ft2/hr
Printing Modes:
White 5 Layers**
High Quality: 43 ft2/hr
Specialty: 32 ft2/hr
High Quality: 43 ft2/hr
Specialty: 32 ft2/hr
Print Resolution Up to 1,800 dpi Up to 1,800 dpi
Print Resolution Canon UVgel 460 ink Canon UVgel 460 ink
Ink Color CMYK / CMYKW**** CMYK / CMYKW****
Ink Packaging 1 x 700ml ink bottle

Ink Reservoir per ink color: 1.8 liter
Can Refill while printing

1 x 700ml ink bottle
2 x 1 liter ink bottle
Ink Reservoir per ink color: 2.1 liter
Can Refill while printing
Printhead 4 or 5* UVgel 425 Printheads
High frequency drop-on-demand piezo-electric printhead
PAINT (Piezo Acoustic Integrated Nozzle Technology)
Automatic Maintenance
Curing: UV LED
4 or 5* UVgel 425 Printheads
High frequency drop-on-demand piezo-electric printhead
PAINT (Piezo Acoustic Integrated Nozzle Technology)
Automatic Maintenance
Curing: UV LED
Media Roll Width: Up to 64” (1,625 mm)
Print Margin: 0.21” (5.3 mm)2
Roll Weight: Up to 110 lbs (50 kg)
Roll Diameter: Up to 8.7” (220 mm)
Media Thickness: Up to 0.03” (0.8 mm)
Roll Width: Up to 64” (1,625 mm)
Print Margin: 0.21” (5.3 mm)2
Roll Weight: Up to 110 lbs (50 kg)
Roll Diameter: Up to 8.7” (220 mm)
Media Thickness: Up to 0.03” (0.8 mm)
Media Input 1 roll or optional 2nd roll**
Print Side Out Media
Print Side In / Double Sided Media**
Magnetic Media Kit**
1 roll or optional 2nd roll**
Print Side Out Media
Print Side In / Double Sided Media**
Magnetic Media Kit**
Jumbo Roll Interface**
UVgel Technology Instant pinning** and dot gain control
Low temperature curing
Scratch resistance
Easy lamination, smooth ink film
High precision color consistency
Odorless and instant dry prints
Instant pinning and dot gain control
Low temperature curing
Scratch resistance
Easy lamination, smooth ink film
High precision color consistency
Odorless and instant dry prints
Certifications Environmental and Safe Use:
GREENGUARD Gold
Environmental and Safe Use:
GREENGUARD Gold
Software Supported Rips:
ONYX Graphics, Caldera, EFI, PrintFactory, ColorGATE, ErgoSoft, Shiraz, AGFA, SAIPRISMA Applications:
PRISMAguide XL
PRISMA remote app
PRISMAservice
Supported Rips:
ONYX Graphics, Caldera, EFI, PrintFactory, ColorGATE, ErgoSoft, Shiraz, AGFA, SAIPRISMA Applications:
PRISMAguide XL
PRISMA remote app
PRISMAservice
External Modules None Jumbo Roll Loader
X/Y Cutter
Rewinder
Jumbo Roll Rewinder
Interface Ethernet (100/1,000 Mbit/s) Ethernet (100/1,000 Mbit/s)
Dimensions Printer W x D x H 3,020 x 1,095 x 1,300 mm Printer W x D x H 3,020 x 1,095 x 1,300 mm
Weight 750 kg 750 kg
Working Environment
Operation Printer 18 – 30°C (recommended 20 – 27°C), 20 – 80% RH (no condensation) 18 – 30°C (recommended 20 – 27°C), 20 – 80% RH (no condensation)
Power 0 W – Off, 250 W – Standby, 1.6 kW – Ready, 2.3 kW – Printing 0 W – Off, 250 W – Standby, 1.6 kW – Ready, 2.3 kW – Printing
Consumption 2 inputs, each 200-240V +/- 10%, 50/60 Hz, 16/6 A. 2 inputs, each 200-240V +/- 10%, 50/60 Hz, 16/6 A.
Source Printer is declared under Radio Equipment Directive (RED)- 2014/53/EU Printer is declared under Radio Equipment Directive (RED)- 2014/53/EU
Regulatory Certification
Declaration of conformity Compliant with EN62479, EN301 489-1, EN301 489-3, EN300-330
FCC Part 15 and RSS-210 certified (module)
Compliant with EN62479, EN301 489-1, EN301 489-3, EN300-330
FCC Part 15 and RSS-210 certified (module)
Radio IEC/EN/UL/CSA 62368-1 compliant Applicable marks: CE, TÜV-GS, C-UL-US, RCM IEC/EN/UL/CSA 62368-1 compliant Applicable marks: CE, TÜV-GS, C-UL-US, RCM
Safety Emission: Class A compliant according CISPR 32, FCC part 15 and ICES-003 Immunity: CISPR 35 compliant Emission: Class A compliant according CISPR 32, FCC part 15 and ICES-003 Immunity: CISPR 35 compliant
EMCEnvironmental WEEE, RoHS directive 2011/65/EU, REACH, CE WEEE, RoHS directive 2011/65/EU, REACH, CE

* Base unit requires 4 printheads, adding optional white module requires and additional print head for a total of 5 printheads

**Optional module

**** White ink is an optional module
